WIRES (Wide-coverage Internet Repeater Enhancement System) is an Internet communication system which expands the range of amateur radio communication. For WIRES-X, an amateur node station connecting to the Internet is used as the access point and connects the wireless communication to the Internet. Users’ stations can communicate with other amateur stations all over the world using a node within the radio wave range.
WIRES-X supports the C4FM digital and the clear and crisp voice technology enables high sound quality. By repeating C4FM digital data as it is via the Internet, users can enjoy clear voice communications even if they are thousands of miles away each other. Utilizing the digital communication, the WIRES-X operation is simple, easy and user friendly. Varieties of the new functions as well as voice communications expands opportunities for enjoyment of ham station operation.
Smart Access Functions
WIRES-X automatically connects to nodes and rooms via the Internet. No more need to verify connection IDs or transmit cumbersome DTMF connection codes. Information about nodes and rooms is exchanged via C4FM Digital signaling. Thanks to automatic reconnection to the previous contact, all you need to do is press PTT and start talking. Easily search for new nodes and rooms, and initiate communication promptly when you find an ID that captures your interest.
Activity Monitor Function
Currently active nodes and rooms can be searched in real time, and viewed on the display of your transceiver. The display list is sorted according to the number of stations currently connected to the room, in other words by popularity. This lets you quickly find other active stations to communicate with. Node owners can freely create a room ID using letters and numbers. The ID works a bit like the name of a person. Easy to understand, meaningful names, unique names, memorable names… all are possible and can be used in a targeted search. A history of previous nodes and rooms, and a memory function with five categories makes it a snap to find and connect with a particular ID.
News Station Function
News bulletins (messages, images, voice memos) can be freely uploaded to nodes and rooms. Other users can download the saved news information. For example, sharing traffic information or other local news, or sending a snapshot of a meeting place to fellow operators, as well as a myriad of other uses are possible. It does not matter whether someone is nearby or in a country far away. WIRES-X offers a way to overcome barriers of distance, time, or even language. Welcome to a world of previously unheard-of possibilities for connecting and communicating by way of Amateur Radio and the internet.
Preset Search Function
Search and connect to local node stations with a simple button touch. The system will automatically obtain node station information and setup the required frequency and digital code parameters. Wherever there is a WIRES-X local node station that is reachable by Amateur radio, complicated connection operation steps are no longer necessary. Node station ID, city name, as well as distance and bearing are indicated on the display of the transceiver, and can be checked at a glance. * Now you can communicate worldwide with ease and confidence. (* Only if published by the node station)
Other Notable Features
Digital/Analog Mutual Communication
WIRES-X of course also supports traditional analog FM users. Not only can analog FM stations have a QSO with each other, WIRES-X also permits C4FM Digital stations to communicate with analog FM stations. WIRES-X is an FM friendly digital solution, because Amateur Radio should always allow operators to communicate freely all over the globe.
Node Setup Is Easy With WIRES-X
Establishing the connection between the HRI-200 and a computer is quick and simple, requiring only a single USB cable. Support for USB bus power means that an additional external power supply is not needed. Opening ports in the router also can be done with a simple setting in the WIRES-X software, using the UPnP function. (May not be supported by some routers.) Working your way through complicated router settings is a thing of the past.
